General Specifications

• Decibel level (dB): 52
• Leveling Legs: 4
• Product Weight (lbs): 1.96
• Water Inlet Location: Left Bottom Front
• Made In USA: Yes
• Reconditioned: No
• Shipping Weight (lbs): 83
• Gallery Collection: Yes
• Sound Package: Silent Design 1
• ProductLaunch: NA
• Energy Efficiency Tier Rating: Tier I
• Power Type: Electric
• Size: 24”
• Installation Type: Built-In
• Collection: Frigidaire Gallery

Options

• NSF® Certified Sanitize Option: Yes
• Hi-Temp Wash: Yes
• Heat/No Heat Dry: Yes

Dishwasher Specifications

• Place Settings: 14
• Tub Design: Tall-Tub Design
• Interior: Graystone
• Filter: Stainless Steel
• Food Disposer: Yes
• Multi Speeds: 3
• Rinse Aid Dispenser: Adjustable with Indicator
• Satellite Spray Arm: OrbitClean®
• Smart Soil Sensor: Yes
• Wash Levels: 5
• Wash System: Direct Feed
• Filter Trap: Removable
• Filtered Water (%): 100
• Integral Air Gap on Supply: Yes
• Drying System: SaharaDry™
• Interior Light: No
• Water Pressure (PSI): 20 – 120
• Water Usage (Gallons): 4.9 – 8.5
• Hard Food Disposer or Filtration: Hard Food Disposer & Filtration
• Automatic Temperature Control: Yes
• Quiet Designation: Quietest in Class

Cut-Out Dimensions

• Cut-Out Depth: 24″
• Cut-Out Height: 34-1/4″
• Cut-Out Width: 24″

Certifications & Approvals

• ENERGY STAR® Certified: Yes
• ADA Compliant: No
• UL Listed: 1-UL Listed
• CSA Listed: Yes
• NSF® Certified: Yes
• ETL Listed: No

Rack System

• Rack Coating: Nylon TufRacks™

Electrical Specifications

• Amps @ 120 Volts: 10
• Power Supply Connection Location: Front Right Bottom
• Voltage Rating: 120V 60Hz

Controls

• Controls: Fully-Integrated
• Digital Display: Yes
• Control Lock: Yes
• Delay Start (hours): 1 – 24 Hours

Upper Rack

• Adjustable Rack Height: Yes
• Cup Shelf: 2
• Folding Bowls Tines: Yes
• Plate – Height Clearance: 8″ – 7-3/8″
• Rack Handles: Yes
• Stemware / Champagne Glass Holders: Yes
• Versa-Tray™: No

Exterior Specifications

• Door Latch: Pull Latch
• Door Type: Stay-Put
• Exterior Finish: Smudge-Proof™ Stainless Steel
• Door and Handle Design: Yes

Cycles

• Number of Cycles: 8
• Energy Saver: Yes
• China Crystal: Yes
• Favorite Cycle: Yes
• Heavy: PowerPlus®
• Normal: Yes
• Quick: Yes
• Rinse Only: Yes
• Upper Rack: Yes

Lower Rack

• Fold-Down Tines: 2 Full Rows
• Height Clearance: 11
• Rack Options: 2
• Silverware Basket: 3-Piece Splittable

Exterior Dimensions

• Depth: 25″
• Depth (with Door 90° Open): 49-1/4″
• Height: 33-1/2″ – 35″
• Height (Min.): 33-1/2″
• Width: 24″
