General Specifications

• Decibel level (dB): 47
• Leveling Legs: 3
• Energy Efficiency Tier Rating: Tier I
• Sound Package: SilentDesign™
• Water Inlet Location: Left Bottom Front
• ProductLaunch: 2018
• Gallery Collection: No
• Reconditioned: No
• Made In USA: No
• Power Type: Electric
• Size: 24''
• Installation Type: Built-In
• Collection: Frigidaire Professional

Options

• NSF® Certified Sanitize Option: Yes
• Hi-Temp Wash: Yes
• Heat/No Heat Dry: Yes

Lower Rack

• Fold-Down Tines: 2 Full Rows
• Height Clearance: 11" - 13"
• Rack Options: 0
• Silverware Basket: Electrolux

Exterior Specifications

• Door Latch: Pull Latch
• Door Type: Stay-Put

Cut-Out Dimensions

• Cut-Out Depth: 24"
• Cut-Out Height: 34-35 3/4"
• Cut-Out Width: 24"

Certifications & Approvals

• ENERGY STAR® Certified: Yes
• ADA Compliant: No
• CSA Listed: No
• ETL Listed: No
• NSF® Certified: Yes
• UL Listed: 1-UL Listed
• Meets ASSE 1006 Requirements: Yes

Rack System

• Rack Coating: Nylon TufRacks™
• Rack System: Global Rack

Dishwasher Specifications

• Place Settings: 14
• Tub Design: Tall-Tub Design
• Interior: Stainless Steel
• Filter: Stainless Steel
• Food Disposer: No
• Multi Speeds: Yes
• Satellite Spray Arm: OrbitClean®
• Smart Soil Sensor: Yes
• Wash Levels: 5
• Wash System: Direct Feed
• Water Usage (Gallons): 4.0 - 8.0
• Integral Air Gap on Supply: Yes
• Drying System: EvenDry™
• Filter Trap: Removable
• Water Pressure (PSI): 20 - 90
• Interior Light: No
• Hard Food Disposer or Filtration: Filtration
• Automatic Temperature Control: No

Exterior

• Exterior Finish: Stainless Steel

Controls

• Controls: Fully-Integrated
• Digital Display: Yes
• Control Lock: Yes
• Delay Start - hours: 1 - 24 Hours

Upper Rack

• Adjustable Rack Height: Yes
• Cup Shelf: 2
• Folding Bowls Tines: Fold Down Tines
• Plate - Height Clearance: 8"-10"
• Rack Handles: Yes
• Stemware / Champagne Glass Holders: Yes
• Soft Spikes: Yes

Dishwasher

• Rinse Aid Dispenser: Yes

Weight and Dimensions

• Product Weight (lbs): 105
• Shipping Weight (lbs): 75

Cycles

• Number of Cycles: 7
• Energy Saver: Yes
• China Crystal: Yes
• Favorite Cycle: Yes
• Heavy: Power Plus
• Normal: Yes
• Quick: Yes
• Rinse Only: Yes

Dishwasher: Rack Upper

• Cup Clips: 2

Electrical Specifications

• Amps @ 120 Volts: 15
• Power Supply Connection Location: Front Right Bottom
• Voltage Rating: 120V / 60Hz / 15A
